Autonics GP-A104-T9D9 – Color LCD Graphic Panel
- Interface RS232C: 2 EA
- Display Specifications LCD Type: TFT Color LCD
- Display Specifications Resolution: 800×600 dot
- Display Specifications Display Area: 211.2×158.4mm
- Display Specifications Color: 16,777,216 colors
- Graphic Drawing Memory: 64MB
10.4-Inch Color LCD Graphic Panels
The GP-A104 series graphic panels are 10.4-inch widescreen TFT LCD graphic HMIs offering excellent visibility and data management capability. The resistive touchscreen (analog touch) allows flexible tag arrangements, and the data logger function allows data storing and backup from various control devices. The units can be installed horizontally or vertically, and also feature support for various connection interfaces including USB Host/Device, Ethernet, and CAN.
10.4-Inch Display
The large 10.4-inch display allows users to see more menus, switches, data logs, and other important information on a single screen.
Elegant and Stylish Design
The HMI features an elegant and stylish design with black bezels and hidden logo.
Horizontal or Vertical Installation Depending on User Needs
The panels can be installed horizontally or vertically depending on user needs or applications, offering high installation flexibility.
CAN Communication
The GP-A104 series can be set as a Master device with CANopen communication protocol to connect multiple I/O devices. Autonics ARD Series and ARIO(DeviceNet models) series I/O can be used as slavedevices.
Main Features
- Horizontal/vertical installation
- Various communication interface support: RS232C, RS422/485, Ethernet, CAN
- Device monitoring of connected device possible without screen data
- Multi-language table feature allows users to switch languages with a single button
- atDesigner screen editor software provided
- Various support functions, extensive image library
- Convenient user interface
- 10.4-inch TFT LCD True Color display capable up to 16,777,216 color variations
- Resistive touchscreen allows operation with bare hands, gloved fingers, or stylus
Manufacturer Specs
| General Specifications | |
| Display Specifications LCD Type | TFT Color LCD |
| Display Specifications Resolution | 800×600 dot |
| Display Specifications Display Area | 211.2×158.4mm |
| Display Specifications Color | 16,777,216 colors |
| Graphic Drawing Memory | 64MB |
| Touch method | Analog touch (resistive type) |
| Interface_RS232C | 2 EA |
| Interface Ethernet | IEEE802.3(U), 10/100Base-TX |
| Power supply | 24VDC |
| Protection structure | IP65(front panel, IEC standard) |
| Dedicated Software | atDesigner, atLogic |
| Approval | CE |
| Interface USB(Host) | 1 EA |
| Interface USB(Device) | 1 EA |
| Graphic drawing Performance Language | English, Korean |
| Graphic drawing Performance Text | Bitmap ASCII and vector font |
| Graphic drawing Performance Number of user screen | 100 pages |
| Real-time controller | RTC embedded |
| Accessories | Fixing bracket: 6, battery (included) |
| Environment Ambient temperature | 0 to 50℃, storage: -20 to 60℃ |
| Environment Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Weight | Approx. 1.62kg (approx. 1.07kg) |
