Descripción
- Fluke 3000 FC DMM
- Fluke Ti200/300/400 Infrared Camera
- PC via optional pc3000 FC Adapter
- Fluke Connect Mobile app
| Accuracy is specified as ± ([% of reading] + [number of least significant digits]). All ranges are autoranging. Accuracy is specified from 5 % to 100 % of the range obtained by autoranging, from 18 °C to 28 °C. | |||
| AC voltage | |||
| Range 1 | Resolution | Accuracy2,3,4 | |
| 45 Hz to 500 Hz | 500 Hz to 1 kHz | ||
| 6.000 V | 0.001 V | 1.0 % + 3 | 2.0 % + 3 |
| 6.000 V | 0.001 V | ||
| 600.0 V | 0.1 V | ||
| 1000 V | 1 V | ||
Fluke Connect
See it. Save it. Share it. All the facts, right in the field.
Fluke Connect with ShareLive ™ video call is the only wireless measurement system that lets you stay in contact with your entire team without leaving the field. The Fluke Connect mobile app is available for Android ™ and iOS and works with over 20 different Fluke products—the largest suite of connected test tools in the world. And more is on the way. Go to the Fluke website to find out more.
Make the best decisions faster than ever before by viewing all temperature, mechanical, electrical and vibration measurements for each equipment asset in one place. Get started saving time and increasing your productivity.
Supported smart phones:
- Android™ 4.3 & up
- iPhone® 4s & later
Manufacturer Specs
| V3000 FC General Specifications | |
| LCD w/backlight | 3½ digits, 6000 counts, updates 4/sec |
| Battery type | 2 AA, NEDA 15 A, IEC LR6 |
| Battery life | 400 hours |
| Memory | Record up to 65,000 readings |
| RF communications | 2.4 GHZ ISM Band |
| RF communication range | Open air, unobstructed: Up to 20 m Obstructed, sheetrock wall: Up to 6.5 m Obstructed, concrete wall or steel electrical enclosure: Up to 3.5 m |
| Operating temperature | -10 °C to +50 °C |
| Storage temperature | -40 °C to +60 °C |
| Temperature coefficient | 0.1 X (specified accuracy)/°C (< 18 °C or > 28 °C) |
| Operating humidity | 90 % at 35 °C, 45 % at 40 °C, 45 % at 50 °C |
| Altitude | Operating: 2,000 m Storage: 12,000 m |
| EMC | EN 61326-1:2006 |
| Safety compliance | ANSI/ISA 61010-1 / (82.02.01): 3rd edition CAN/CSA-C22.2 No 61010-1-12: 3rd edition UL 61010-1: 3rd edition IEC/EN 61010-1:2010 |
| Safety rating | CAT IV 600 V, CAT III 1000 V |
| Certifications | CSA, CE, FCC: T68-FBLE IC: 6627A-FBLE |
| Ingress Protection (IP) rating | IP42 |
| Pollution degree | 2 |
| Size (HxWxD) | 16.5 cm x 6.35 cm x 1.4 cm (6.5 in x 2.5 in x 1.4 in) |
| Weight | .22 kg (8 oz) |
| (Not compatible with Fluke CNX test tools) | |
Tech Specs
Dataloggers / Data Acquisition/Voltage Datalogger Template |
|
|---|---|
| Max Voltage | 1000 V |
| Min Voltage | 1 V |
| Power Source | Battery |
| Accuracy | 45 Hz to 500 Hz 1.0 % + 3 500 Hz to 1 kHz 2.0% + 3 |
| LCD Screen | Yes |
| Software Included | Yes |
Test Equipment General Attributes |
|
| Unique Features | With the Fluke v3000 FC Wireless AC Voltage Module you can:
Measure up to 1000 V True-RMS AC. |
| Warranty | 1 YEARS |
| Safety Approval | UL |
| Interfaces I/O | Bluetooth, Other, Wifi |
| IP Rating | IP42 |
| Product Weight | 1.44 LBS |
| Product Height | 9 IN |
| Product Length | 5.18 IN |
| Product Width | 3 IN |
| Shipping Weight | 1.58 LBS |
| Data Logging | Yes |
| HTS/Schedule B Number | 8504.40.9580 |
| ECCN Number | EAR99 |
| Battery Type | Other |
| Power Supply Voltage | Battery Powered |
| Country of Origin | United States |
| Shipping Height | 3.10 IN |
| UPC | 095969692014 |
| Shipping Length | 11.25 IN |
| Shipping Width | 5.30 IN |
