Descripción
Fluke takes ruggedness to a hardcore level with the 28II industrial digital multimeter. We can all be a little careless at times and accidents happen. So don’t worry if you drop the 28II while standing on a ladder and don’t be concerned if your 28II falls into the water. With an IP 67 rating and drop testing rating to 3 meters, the Fluke 28II has you covered.
The NEW standard for rugged.
The NEW Fluke 28 II digital multimeters define a new standard for operating in harsh conditions with the features and accuracy to troubleshoot most electrical problems. The Fluke 28 II has an IP 67 (waterproof and dustproof) rating, MSHA approvals, extended operating temperature range of -15 °C to +55 °C (5 °F to 131 °F, -40 °C for up to 20 minutes) and 95 % humidity, and have been designed and tested to withstand a 3 m (10 ft) drop.
Why the Fluke 28 II?
- Addresses customers who need a heavy duty waterproof and dustproof Digital Multimeter
- Addresses the needs of customers who prefer True-rms
- Extended operating temperature, usable to -40C
- Two year calibration cycle
- Measure up to 1000 V ac and dc
- Measure up to 10 A (20 A for 30 seconds)
- 10,000 µF capacitance range
- Frequency to 200 kHz
- Resistance, continuity and diode test
- Min/Max and average recording to capture variations automatically
- Extended ac voltage bandwidth: 15 Hz to 20 kHz
- Built in thermometer conveniently allows you to take temperature readings without having to carry a separate instrument
- Peak min-max
- Unique function for accurate voltage and frequency measurements on adjustable speed motor drives and other electrically noisy equipment
Manufacturer Specs
| True-rms | |
| Counts | 6000 / 19,999 |
| Voltage 1000 V AC/DC |  |
| Resistance 50 Ω | |
| Continuity/Diode | |
| Capacitance 10,000 µF | |
| Frequency 200 kHz | |
| Low pass filter for working on variable speed drives | |
| Temperature -200 °C to +1090 °C | |
| Min/ Max/ Average,Hold, Auto and Manual Range | +Peak min-max |
| Safety Rating | CAT III 1000 V CAT IV 600 V |
| IP Rating | IP 67 |
| Warranty | Limited Lifetime |
| Size (H x W x L) with Holster |
6.35 cm x 9.91 cm x 23.24 cm |
| Weight with Holster | 1.54 lb.(698.5 g) |
Tech Specs
Multimeters Template |
|
|---|---|
| Style | Hand-Held |
| Measures AC V | Yes |
| Measures DC V | Yes |
| Measures AC A | Yes |
| Measures DC A | Yes |
| True RMS | Yes |
| Maximum Voltage AC | 1000 V |
| Resolution AC Volts | 1 V (1000 mV) |
| Maximum Voltage DC | 1000 V |
| Resolution DC Volts | 1 V (1000 mV) |
| Maximum Current AC | 10 A |
| Minimum Current AC | 0.1 uA (0.00010 mA) |
| Resolution AC Current | 0.01 A (10 mA) |
| Maximum Current DC | 10 A |
| Minimum Current DC | 0.1 uA (0.00010 mA) |
| Resolution DC Current | 0.01 A (10 mA) |
| Basic Accuracy V DC | 0.05 % + 1 |
| # Digit Display | 4.5 |
| Counts | 6000 . |
| Backlight | Yes |
| Manual/Autoranging | Both |
| Decibels | No |
| Resistance | Yes |
| Frequency | Yes |
| Capacitance | Yes |
| Temperature | Yes |
| Diode Testing | Yes |
| CAT Rating | IV |
| CAT Voltage | 1,000 V, 600 V |
| Intrinsically Safe | No |
| Peak Hold | Yes |
| Overload Protector | Yes |
| Wireless Display | Yes |
| Data Hold | Yes |
| Low-Pass Filter | Yes |
| Duty Cycle % | Vdc and mVdc
Range: 0.0 % to 99.9 % Accuracy: Within ± (0.2 % per kHz + 0.1 %) for rise times < 1 μs |
Test Equipment General Attributes |
|
| Unique Features | •Measure up to 1000 V ac and dc
•Measure up to 10 A (20 A for 30 seconds) •10,000 μF capacitance range •Frequency to 200 kHz •Extended ac voltage bandwidth– 15 Hz to 20 kHz •Built in thermometer conveniently allows you to take temperature readings without having to carry a separate instrument •Resistance, continuity and diode test •Min/Max and average recording to capture variations automatically •Peak min-max •Unique function for accurate voltage and frequency measurements on adjustable speed motor drives and other electrically noisy equipment •New – IP 67 waterproof & dustproof protection, completely sealed for use in harsh environments •Designed to withstand 3 meter drop (with holster) |
| Warranty | 10 YEARS |
| Additional Info/Comments | •Hi resolution 20,000 count display mode
•True-rms ac voltage and current for accurate measurements on non linear signals •New – Backlit keypad buttons allow for easy visibility in lowlit areas •Large display digits and 2 level bright white backlight for increased visibility •Reversible holster for added protection when not in use •Withstands hazardous 8,000 volt spikes caused by load switching and faults on industrial circuits and complies with second edition IEC and ANSI electrical safety standards •Long battery life (800 hours) •Relative mode to remove test lead resistance from low ohms measurements •Auto and manual ranging for maximum flexibility •Optional magnetic hanger for easy setup and viewing while freeing your hands for other tasks •MSHA approval |
| Safety Approval | CE, CSA |
| Interfaces I/O | Analog Output, Analog Input |
| IP Rating | IP67 |
| Product Weight | 1.14 LBS |
| Product Height | 1.8 IN |
| Product Length | 8.4 IN |
| Product Width | 3.95 IN |
| Shipping Weight | 2.65 LBS |
| Data Logging | No |
| ECCN Number | 3A992 |
| Calibration Included | None |
| Battery Type | AA |
| Power Supply Voltage | Battery Powered |
| Country of Origin | United States |
| Shipping Height | 5.91 IN |
| UPC | 095969461719 |
| Shipping Length | 12.99 IN |
| Shipping Width | 11.02 IN |
