Hioki 3280-70F – Clamp On Hi Tester with CT6280 Flexible AC Clamp
- Temperature measurement
- Ohmmeter circuit tested to 250 V AC over voltage-OK
- Clamp-on measurement for busbars and thick conductor
- Independent-opening double-lever design
Measure 1000Amp AC Mean (Average) Current Hioki gauranteed quality. Three year warranty. Slim body design, allows easy clamping even for narrow conductors.
42A to 1000A AC Current Clamp Meters with Double Opening Jaw and Slim Profie to Get into the Narrowest Spaces
Hioki clamp on meters are best-in-class measuring devices incorporating Hioki’s expertise in current sensing technology. The 3280-10 and 3280-20 are our most popular clamp on meters, featuring a thin and compact clamp core that lets you get into the tightest spots.
True RMS vs. MEAN Value
Two ways to convert alternating current to RMS are “true RMS response” and “average rectified RMS response” (averaging). Both display the same value for a sine wave, but can display very different values for distorted waveform.
Tech Specs
Clamp Meters/Clamp Meters Template |
|
|---|---|
| True RMS | No |
| Maximum Current AC | 1000 A |
| Maximum Voltage AC | 600 V |
| Maximum Voltage DC | 600 V |
| Resistance | Yes |
Test Equipment General Attributes |
|
| Product Height | 2.25 IN |
| Product Length | 9.00 IN |
| Product Width | 3.50 IN |
| Country of Origin | Japan |
| Shipping Height | 2.25 IN |
| Shipping Length | 9.00 IN |
| Shipping Width | 3.50 IN |
