Descripción
Extech HDV640W – HD VideoScope Kit with Wireless Handset/Articulating Probe
- Inspect in walls for mold, insect infestation, electrical wire or water pipe location
- Inspect inside ducts, behind motors & compressors
- View inside or around engines & transmissions
- Safety and security inspections
- Inspect weld integrity, process equipment, gears, molding machines.
- Aircraft inspections for debris or damages.
The Extech HDV640W High Definition Wireless Articulating VideoScopes features a 6mm diameter camera with a 320° articulating tip for the best viewing angle. Easy one-hand operation of the articulating camera tip facilitates viewing in obstructed areas where standard camera tips cannot access. Images and videos are viewed on the large high-resolution color display and can be stored in the SD memory card(included).
Inspect concealed plant equipment, gearboxes, pipelines, and more with the rugged Extech HDV640W wireless high-definition industrial videoscope, which delivers images and videos with remarkable sharpness and clarity. It offers easy one-handed operation of the articulating camera tip, perfect for viewing in obstructed areas where standard camera tips cannot access.
Images and videos are viewed on the large, high-resolution color display and can be stored on the included SD memory card. A built-in wireless transmitter in the camera cable control enables you to transmit video up to 100 feet (30 meters) from the measurement point to your monitor.
Designed for use in practically any environment, the HDV640W features a 5.7-inch color display (640 x 480-pixel resolution) for bright outdoor sites or poorly lit facilities. Optics include 4mm-6mm LED-illuminated camera probes, and the camera head has four built-in bright LED lamps with dimmer to illuminate the viewed object. The articulated controller handset features 320-degree articulated 6mm scopes and a large, glove-friendly, articulation control knob with adjustable resistance, helping simplify inspections of detail-intensive equipment.
The included 1 GB SD card can store up to 15,000 images or up to 4 hours of video with audio annotations to help eliminate manual note-taking. Video and images can also be viewed on an external monitor thanks to the AV output, or transferred to a PC via the unit’s USB output.
This Extech videoscope is tested waterproof to IP67 standards and drop-proof to 2 meters. It has an internal 3.7-volt rechargeable lithium-polymer battery that provides up to 4 hours of use, and it’s backed by a one-year limited warranty.
Manufacturer Specs
| Specifications | |
| Camera | |
| Minimum Focus distance | 2.36″ (60mm); macro: 0.59” (15mm) |
| Field of View | 65° |
| Shaft diameter | 0.24″ (6mm) |
| Working length | 39″ (1m) |
| Camera Tip bending | 320° (from straight position 160° left, 160° right) |
| Borescope | |
| LCD Screen Type | 5.7″ color TFT |
| Pixels | 640 x 480 (High Definition) |
| SD Card | 1GB (included) |
| Operating | 4 hours |
| Includes: | |
| SD memory card, 3.7V rechargable Li-Polymer battery, patch cable, AC adaptor, USB and AV cables, camera with cable, and hard carrying case | |
Tech Specs
Borescopes / Boroscopes/Video Borescopes Template |
|
|---|---|
| Shaft Length | 39 IN |
| Shaft Diameter | 6 MM (0.006 M) |
| Screen Size | 5.7 IN |
| Detachable Screen | No |
| Screen Type | TFT LCD |
| Image Resolution | 640 x 480 |
| Video Output Format | NTSC, PAL |
| IP Rating | IP57, IP67 |
Test Equipment General Attributes |
|
| Unique Features | wireless |
| Warranty | 1 YEARS |
| Safety Approval | CE |
| Interfaces I/O | USB |
| Storage | SD Card |
| Product Height | 7.00 IN |
| Product Length | 24.25 IN |
| Product Width | 15.50 IN |
| Data Logging | No |
| HTS/Schedule B Number | 9013.80.9000 |
| ECCN Number | EAR99 |
| Calibration Included | Factory Calibration |
| Battery Type | Other |
| Power Supply Voltage | Battery Powered |
| Country of Origin | Taiwan |
| Shipping Height | 7.00 IN |
| Shipping Length | 24.25 IN |
| Shipping Width | 15.50 IN |
