12-CHANNEL TEMPERATURE EXCEL-FORMATTED DATA LOGGING SD CARD
12 Channel Thermometer with SD Card accurately measures 12 Channels of Temperature from -148 to 3092 F; -100 to 1700 C. This 12 channel thermometer with SD card’s unique feature is its patented technique for storing sampled data in Excel format on removable SD memory cards.
Manufacturer Specs
| Specifications | |
| Display | 2.05 x 1.5 in. (52 x 38mm) LCD |
| Measurement Range | With included “K” type thermocouples: -148° to 2372°F (-100° to 1300°C) With other thermocouples: depends on type |
| Measurement Accuracy | With included “K” type thermocouples: ± (0.4 % of reading + 2.0°F max) |
| Operating Temperature | 32° to 122°F (0° to 50°C) |
| Operating Relative Humidity | 0 to 85% |
| Dimensions | 8.86 x 4.92x 2.52 in. (225 x 125 x 64mm) Weight: 2.1 lb. (944g) |
| Power Source | Eight “AA” batteries or optional 9-VDC AC adapter |
Tech Specs
Dataloggers / Data Acquisition/Dataloggers for Environmental Variables/Temperature Dataloggers Templ |
|
|---|---|
| Type | E, J, K, Other, S, T |
| Max Temperature | 3092 F (1700 C) |
| Min Temperature | -148 F |
| Power Source | AC Line |
| Accuracy | With Types K, J, T and E thermocouples: ± (0.4% of reading + 2.0ºF max) With Types R and S: ±(0.5% of reading + 2.0ºF) |
| LCD Screen | Yes |
| Software Included | No |
Test Equipment General Attributes |
|
| Unique Features | Twelve independent temperature measurement channels Displays up to eight channels at a time; one push of a button switches to Channels 9 through 12 Works with and automatically temperature compensates for six popular thermocouple types: K, J, T, E, S and R Combining thermocouple types extends overall measurement range to -148° to 3092°F (-100° to 1700°C) Can automatically log 12 channels of data every day during same period |
| Warranty | 1 YEARS |
| Storage | SD Card |
| Product Weight | 2.1 LBS |
| Product Height | 2.52 IN |
| Product Length | 8.86 IN |
| Product Width | 4.92 IN |
| Data Logging | Yes |
| HTS/Schedule B Number | 9031.80.8085 |
| ECCN Number | 3A992 |
| Country of Origin | United States |
| Shipping Height | 4.50 IN |
| Shipping Length | 14.80 IN |
| Shipping Width | 15.75 IN |
