Lascar EL-USB-ULT-LCD USB Ultra Low Temperature Data Logger with Display
- Logging rates between 1 second and 12 hours
- Measurement range -100 to +100°C (-148 to +212°F)
- T-Type probe on 1m cable
- Stores over 32,000 readings
The EL-USB-ULT-LCD is designed to monitor vaccines in cryogenic dry ice storage.
This standalone data logger measures and stores more than 32,000 temperature readings from its high accuracy thermocouple temperature probe.
The user can easily set up the logger and view downloaded data by plugging the data logger into a PC’s USB port and using the free EasyLog software. Data can then be graphed, printed and exported to other applications for detailed analysis.
The high contrast LCD can show a variety of temperature information. At the touch of a button, the user can cycle between the current, maximum and minimum stored values for temperature.
The data logger is supplied with a lithium metal battery which typically gives 2 years’ logging life.
Manufacturer Specs
| General Specifications | |
| Temperature measurement range | -100 to +100°C (-148 to +212°F) |
| Internal resolution | 0.5°C (1°F) |
| Accuracy (overall error) | ±2.5°C (±4.5°F) typical |
| Logging rate | User selectable between 1 second & 12 hours |
| Operating temperature range | -10 to +40°C (+14 to +104°F) (data logger only) |
| Battery Life | 2 years (at 25°C and 1 minute logging rate) |
| Readings | 32,510 |
| Dimensions | 135 x 24 x 21mm (5.31 x 0.94 x 0.82″) |
| Probe dimensions | 300 x Φ 1.5mm, 1m cable (11.8 x Φ 0.05, 39.3″ cable) |
