Description
TPI 183aC3 – HVAC DMM/Clamp Meter kit
- Trouble shoot ECMs and VFDs
- Measure duty cycle (% pulse width modulation) on modulating gas valves
- Measure heat anticipator current in thermostats
- Test heating element and compressor winding resistance
The 183 is a hand-held autoranging DMM. The backlit LCD can display three readings at one time. In addition to the basic functions of ACV, DCV, ACA, DCA, Diode Test, and Continuity, the 183 measures Frequency (Hz) and Capacitance. The 183 also has RS232 output and software for recording information into a PC.
The 183A also features:
- REC – Records Min/Max and Average readings during specified measurement intervals. Time reference can also be displayed to determine when the values were recorded.
- COMP – Compare the actual reading to preset HI and LOW values for Pass/Fail to test of components.
- HOLD – Two-hold system automatically holds the previous stable reading when a new one is obtained.
Applications
- Test run and start capacitors
- Measure ambient and duct temp
- Test control (thermostat, thermocouple, flame safety) and line voltages
- Measure resistance and test for continuity
- Line current up to 10 amps (in series)
Tech Specs
Clamp Meters/Clamp Meters Template |
|
|---|---|
| Resistance | Yes |
| Capacitance | Yes |
| Auto Ranging/Manual | Auto Ranging |
Test Equipment General Attributes |
|
| Shipping Weight | 3.05 LBS |
| Country of Origin | Korea |
Reviews
There are no reviews yet.
