Lascar EL-USB-ULT PLUS USB Ultra Low Temperature Data Logger
- Measurement range -100 to +100°C (-148 to +212°F)
- High accuracy T-type probe on 2m cable
- Stores over 32,000 readings
- Logging rates between 1 second and 12 hours
- Immediate and delayed logging start
The EL-USB-ULT+ is designed to monitor vaccines in cryogenic dry ice storage.
This standalone data logger measures and stores more than 32,000 temperature readings from its high accuracy thermocouple temperature probe.
The user can easily set up the logger and view downloaded data by plugging the data logger into a PC’s USB port and using the free EasyLog software. Data can then be graphed, printed and exported to other applications for detailed analysis.
The data logger is supplied with a lithium metal battery which typically gives 2 years’ logging life.
Manufacturer Specs
| General Specifications | |
| Temperature measurement range | -100 to +100°C (-148 to +212°F) |
| Internal resolution | 0.5°C (1°F) |
| Accuracy (overall error) | +2.5°C (+4.5°F) typical |
| Logging rate | User selectable between 1 second & 12 hours |
| Operating temperature range | -10 to +40°C (+14 to +104°F) (data logger only) |
| Battery Life | 2 years (at 25°C and 1 minute logging rate) |
| Readings | 32,510 |
| Dimensions | 135 x 24 x 21mm (5.31 x 0.94 x 0.82″) |
| Probe dimensions | 300 x Φ 1.5mm, 1m cable (11.8 x Φ 0.05, 39.3″ cable) |
Tech Specs
Test Equipment General Attributes |
|
|---|---|
| Shipping Weight | 0.78 LBS |
| ECCN Number | EAR99 |
| Country of Origin | China |
