Descripción
Amprobe ACD-6 PRO
- 1000 Amp AC current
- AC/DC voltage to 600V
- Resistance
- Continuity Beeper
- Relative zero mode
- Auto power off
1000A Clamp-on Multimeter
This high-current clamp doubles as a multimeter for AC and DC voltage, resistance and continuity. It is simple to operate and well-suited for high current applications.
Manufacturer Specs
| AC Voltage | 4.000/40.00/400.0/600V ±(2.0% Rdg + 5 LSD) @ 4-400V range, 50 & 60 Hz |
| DC Voltage | 400.0mV/4.000/40.00/400.0/600V ±(1.7% Rdg + 3 LSD) @ 4-400V range |
| Resistance | 400.0Ω, 4.000/40.00/400.0kΩ, 4.000/40.00MΩ ±(1.0% Rdg + 4 LSD) @ 400Ω-400kΩ range |
| AC Current | 400.0/1000 A ±(1.5% Rdg + 5 LSD) @ 50 & 60Hz |
| UPC/DCI | 12932 |
| Warranty | Limited Life Time Warranty |
| Safety | Cat III 600 V |
Tech Specs
Clamp Meters/Clamp Meters Template |
|
|---|---|
| True RMS | No |
| Maximum Current AC | 1000 A |
| Maximum Voltage AC | 600 V |
| Maximum Voltage DC | 600 V |
| Maximum Conductor Size | 1.77 IN |
| Resistance | Yes |
| Capacitance | No |
| Auto Ranging/Manual | Both |
| In-Rush Current | No |
Test Equipment General Attributes |
|
| Unique Features | Relative Zero Mode, Low Battery Indication |
| Warranty | 1 YEARS |
| Warranty Details | 1 Year from the Date of Purchase |
| Additional Info/Comments | Line Splitter (Energizer), 3000A AC Flexible Clamp-on Attachment, Single Input Thermocouple Temperature Attachment, Alligator Clips |
| Product Weight | 220 GRAMS (0.485 LBS) |
| Product Height | 40 MM (1.57 IN) |
| Product Length | 224 MM (8.82 IN) |
| Product Width | 78 MM (3.07 IN) |
| Data Logging | No |
| Battery Type | CR2032 |
| Power Supply Voltage | Battery Powered |
| Country of Origin | Taiwan |
| Shipping Height | 3.10 IN |
| Shipping Length | 11.90 IN |
| Shipping Width | 6.70 IN |
| Other Information | AC Voltage: 4.000/40.00/400.0/600V ±(2.0% Rdg + 5 LSD) @ 4-400V range, 50 & 60 Hz
DC Voltage: 400.0mV/4.000/40.00/400.0/600V ±(1.7% Rdg + 3 LSD) @ 4-400V range Resistance: 400.0?, 4.000/40.00/400.0k?, 4.000/40.00M? ±(1.0% Rdg + 4 LSD) @ 400?-400k? range AC Current: 400.0/1000 A ±(1.5% Rdg + 5 LSD) @ 50 & 60Hz UPC/DCI: 12932 Warranty: Limited Life Time Warranty Safety: Cat III 600 V |
