Descripción
Manufacturer Specs
| General | |
| AC Current | 2, 20, 200, 400A (0.001A) |
| DC Current | 40, 400A (0.01A) |
| Basic accuracy | ±2.5% |
| DC Voltage | 200mV, 2V, 20, 200V, 600V (0.1mV) |
| AC Voltage | 200mV, 2V, 20V, 200V, 600V (0.1mV) |
| Basic accuracy | AC: ±1.5% DC: ±1.2% |
| Resistance (Ω) | 200, 2k, 20k, 200k, 2M, 20M (0.1 ‰ ) |
| Capacitance | 40nF, 400nF, 4μF, 40μF, 100μF (0.01nF) |
| Frequency | 5Hz, 50Hz, 500Hz, 5kHz, 150kHz (0.001Hz) |
| Temperature | -58 to 1830°F (-50 to 1000°C) (1°) |
| Duty Cycle | 0.5 to 99.0% (0.1%) |
| Continuity | Beeper ≤30 Ω |
| Power | Two AAA batteries |
| Dims/Wt. | 7.9x2x1.4″ (200x50x35mm)/ 7oz |
Tech Specs
Clamp Meters/Clamp Meters Template |
|
|---|---|
| True RMS | No |
| Maximum Current AC | 400 A |
| Maximum Current DC | 400 A |
| Maximum Voltage AC | 600 V |
| Maximum Voltage DC | 600 V |
| Maximum Conductor Size | 0.9 IN |
| Resistance | Yes |
| Capacitance | Yes |
| Auto Ranging/Manual | Auto Ranging |
| In-Rush Current | No |
Test Equipment General Attributes |
|
| Unique Features | Compact Size Allows Measurements in Tight Locations, High Accuracy for Current Measurements, Data Hold Freezes Current Reading on Display, Overrange and Low Battery Indicators |
| Additional Info/Comments | Duty Cycle Function |
| Product Weight | 0.44 LBS |
| Product Height | 1.38 IN |
| Product Length | 7.87 IN |
| Product Width | 1.97 IN |
| Data Logging | No |
| Battery Type | AAA |
| Power Supply Voltage | Battery Powered |
| Country of Origin | China |
| Shipping Height | 2.80 IN |
| Shipping Length | 10.70 IN |
| Shipping Width | 6.20 IN |
